Immunocytochemical Reactions in the Brittle-Star: Ophiocomina Nigra after Immunization

Materials and Methods

Ophiocomina nigra were obtained from the Marine Biological Institute of Gothenburg and placed in aquarium with running sea water. 20 animals were put in three parts:

1. Control ones (6 animals): first aquarium
2. BSA (Bovine serum albumin) ones (7 animals): 2d aquarium
3. HRP (Horse-radish peroxydase)ones (7 animals): 3d aquarium Control animals were not immunized.

On the other hand BSA animals received at time t=0 10µl of BSA (1mg/ml solution) and at time t=7 days after, again, 10µl of BSA (same concentration). HRP animals received 10µl of HRP (Sigma Products) of a solution at 1mg/ml at times similar as those of BSA animals then a second injection of 10µl of HRP. 3 days after the last injection. All animals were sacrifiied and axial organs (A.O) were excised. Fixation of A.O in glutaraldehyde occured (2 % in cacodylate buffer). Then A.O were washed in buffer. Incubation in HRP (1mg/ml) was performed for all A.O. Washing in buffer was following.

Incubation in diaminobenzidin (1mg/ml) and H2O2 (1 drop) was realized then washing in buffer occured O/N. We did dehydratation in alcohol and then embedding in paraffin. Sectioning was made at 4µ. We used Heathrow scientific LLC slides. Coloration was performed with Giemsa (1 min). Observations were done with a microscope Zeiss.

Results

Briefly we observe neither labelling in control animals, nor in BSA treated animals. In immunized animals to HRP a positive labeling (color dark-brown) occurs in hyaloplasm in ergastoplasm and sometimes in the perinuclear space (Figures 1 & 2). Labelling is about 5 % of the whole cell population. It is of 0 % for BSA treated animals. Plasmolymphocytoplasmic and lymphocytes cells seem to exist in Ophiocomina nigra as for Asterina gibbosa [1] but it must be corroborated by TEM observations.

Click to enlarge

Click to enlarge

Discussion and Conclusion

It is shown that antigen-antibody like reactions occur in the brittle star: Ophiocomina nigra. It opens an immense field of experiments we may compare to those of Asterids (another echinoderm): i.e; research of lymphocytes (like sea star B and T lymphocytes) Research of Primitive Brittle star antibody, and brittle star genomic studies [4]. In fact, it would be interesting to study the genome of O.nigra and to compare the sea star immune genes to brittle star ones. We hope that the present work will help in suggesting provocative and imaginative ideas on adaptative immunity in marine invertebrates.
