Non-ablative Fractional Laser as an Emerging Treatment for Alopecia Areata

Introduction

Alopecia areata (AA) is an immune mediated non scarring type of hair loss that can affect males and females at all ages. It has a lifetime risk estimated of 1,7%- 2,1% [1, 2]. The most commom clinical patterns are patchy alopecia (localized round or oval areas of alopecia), alopecia totalis (loss of all scalp hair), alopecia universalis (loss of all scalp and body hair) and ophyasis pattern (alopecia of the periauricular área and the lower occipital scalp). AA may also affect nails, eyelashes, eyebrows and other body hairs. Extensive and/or persistent cases can cause severe psychologycal distress.

There is currently no drug approved by the Food and Drug Administration (FDA) for the treatment of this disease, however topical and intralesional corticosteroids are commomly used with variable results [3].

More recently, another approach for AA that have been reported in the literature is the use of fractional lasers [4, 5].

In here we report on two cases of extensive alopecia areata treated with combination of intralesional corticosteroids followed by fractionated laser photothermolyses.

Case Reports

For intralesional injections, a combination of triamcinolone acetonide 20mg/mL and lidocaine hydrochloridre 2% with epinephrine were used, in a final concentration of 5mg/mL of the corticosteroid.

Laser treatment was performed with a non-ablative 1550nm fractional erbium glass laser (Fraxel®, Solta Medical, Hayward, CA). At each laser session, eight passes per affected area were performed, at 10 mJ of energy and density of 672 MTZ/cm2. Case 1 A 24-year old female with a 4 years history of alopecia areata totalis, presented total scalp hair loss and hair loss of the distal third of the left eyebrow (Figures 1A-C).

Click to enlarge

Eyelashes and body hair were not affected. The patient received 6ml of intralesional injections of triamcinolone and lidocaine at each treatment session. A vibratory device (Brookstone ®) was used during the procedure to minimize the pain. After injections, fractional laser was applied to the entire scalp. Treatment was performed once a month, for 6 months. The patient was already using clobetasol shampoo before the treatment, without any significant improvement. She was advised to continue applying the shampoo 3 times a week. After 4 months, she had developed isles of regrowth diffusely, with thick and pigmented terminal hairs (Figures 1D-F). A few areas of atrophy on the scalp could also be observed. Injection was avoided in those atrophic areas in the remaining sessions. After 6 months, she presented with more areas of regrowth and overall improvement (Figures 1G-1I).

Figures 1A, 1B and 1C: Before treatment.

Figures 1D, 1E and 1F: After 4 treatment sessions.

Click to enlarge

Figures 1G, 1H and 1I: After 6 treatment sessions. Case 2

A 59-year old female with a history of 2 years of extensive patchy alopecia areata, underwent treatment with 4mL of triamcinolone and lidocaine intralesional injections (Figures 2A-G). A vibratory device (Brookstone ®) was used concomitant the injections to minimize the pain. After injections, fractional laser was applied to the

Figures 2A , 2B, 2C and 2D: Before treatment.

Click to enlarge

Figures 2E, 2F and 2G: After 8 treatment sessions.

Discussion

The pathogenesis of AA is complex and not yet completed elucidated, however there is significant evidence indicating the participation of a T-cell mediated autoimmune reaction against hair follicles, targeting actively growing anagen hairs [6]. These findings support the use of steroids as a first line treatment modality for AA.

In extensive disease, systemic steroids are usually preferred, however the side effects and relapse rates can limit its use. The intradermal application of intralesional steroids in low concentration in these cases resulted in minimal atrophy rate. Discomfort during the procedure was reduced with the use of lidocaine and a vibratory stimuli resulting in a minimally painful treatment.

The study of lasers in the treatment of diferente types of alopecia started after the observation of “paradoxal hyperthricosis”, in which patients treated with lasers and/or intense pulsed light for photoepilation presented hair growth [7, 8].

The stimulation of hair growth during the process of wound healing is another finding that supports the basis for the use of laser to treat hair loss [9].

Fractional laser application is though to induce hair growth by creating microscopic thermal columns in the dermis that induce controlled injury zones. The small wounds formed stimulate changes in cytokines and growth factors expression, allow a rapid epidermal repair and a premature anagen entry [4, 10, 11]. It is postulated that the thermal stimulus could also increase blood flow in the dermal papilla and induce T-cell apoptosis or decrease inflammation [4, 5, 12]. Furthermore, fractional light sources do not cause hair removal because it has no affinity for melanin [5]. The energy is mostly absorbed by water, sparing the superficial layers of epidermis from the excessive thermal damage thus minimizing side effects [13].

Animal studies involving C3H/HeN mice suggested that the 1550-nm fractional erbium-glass laser induces hair growth by increasing Wnt 5a [beta]-catenin signals and augmenting anagen conversion of hair [14].

Conclusion

The pathophysiology of the lasers that take effect on hair regrowth in AA is still unknown. The interest in studying lasers in the treatment of AA have increased in the past few years. Although the results had been variable, majority of the cases exhibited favorable and positive therapeutic outcomes [13].

The few cases reported in the literature using fractional laser therapy for AA demonstrated no significant side effects [4, 5].

Intralesional injections of corticosteroids have been used for several years, with variable results and no significant side effects.

This suggests that intralesional steroids combined with laser application may be a safe and effective combination treatment for extensive AA.

The development of randomized controlled clinical trials with longer follow up periods are needed to establish optimal laser parameters and standardized treatment protocols using either the combination therapy or only laser treatment.
