Molecular Sphere Radii of H2O and D2O to Achieve Rotational Brownian Motion

Introduction

When a sphere of radius a is immersed in a Newtonian viscous fluid such as water, and it performs a one-dimensional translational motion, the resistive drag required to maintain a steady velocity is described by Stokes’ law, which is derived from the Navier–Stokes equation [1, 2]. When an electric field E is applied to the solvent water containing solute molecules regarded as spheres, the equilibrium between the electric force and the resistive drag moves the solute molecule with steady electrophoretic velocity, which is called the electrophoretic formula (EPF) [3, 4, 5]. According to Walden’s rule, the vep follows the distinct change in the viscosity with temperature. Thus, the Avogadro number average is employed to ensure that a Navier–Stokes equation using a viscosity determined on a macroscopic scale is applicable to electrophoresis performed at a molecular scale.

When the solute molecule regarded as a sphere is immersed in solvent water, the thermal agitation causes the molecular sphere to carry out random walks in translational and rotational directions, which are called translational Brownian motion (TBM) and rotational Brownian motion (RBM), respectively [3, 4, 6, 7, 8, 9, 10]. The time averages of the cumulative random walks cause the squared values of the translational and rotational average displacements to be proportional to time. These proportional coefficients are called translational (D) and rotational ($D_{\text{rot}}$) diffusion coefficients, respectively. When the solute and solvent are similar, the D is called the self-diffusion coefficient $D_{\text{self}}$. When the molecular sphere performs a rotational motion, a force couple (torque) is required to maintain a stationary angular velocity [1, 8, 9, 10]. The D and $D_{\text{rot}}$ are derived from the equilibria between the thermal energy and resistive drag (Stokes' law), and that between the thermal energy and the force couple, which are called the Stokes–Einstein equation (SEE) and the dielectric relaxation formula (DRF), respectively. A molecular radius can be calculated using the SEE, DRF, or EPF; that calculated using the SEE is called a Stokes radius. The radius is very frequently estimated from D using the SEE because the D can be measured without application of alternating or direct electric field. Two inaccuracies with regard to the Stokes radius have been noted [11, 12, 13]. First, a molecular radius calculated using the SEE will be smaller than the van der Waals (electron cloud) radius; [14] Second, the temperature dependence of the Stokes radius is very high; thus, Walden's law does not hold for the SEE; this tendency is most distinct for lower molecular weight (MW) molecules such as water ($H_2O$) and heavy water ($D_2O$) molecules [11, 12, 13].

Studies of the restricted diffusion coefficients; $resD_{\text{self}}$ of water and $resD$ of solute in the restricted water solvent are in progress. The values of $resD_{\text{self}}$ in the porous materials have been measured, where the void ratio and water content rate are measured by comparing $D_{\text{self}}$ in free water and $resD_{\text{self}}$ in restricted water [15]. The $resD_{\text{self}}$ observation using magnetic resonance (MR) imaging is attempted because $resD_{\text{self}}$ provides useful diagnostic information of activity and lesions in living tissues [16, 17]. Although the value of D for solutes in water is determined by optical measurements (OMs) [3, 11, 12, 13, 14, 15, 16, 17, 18]. The exact D at the zero-concentration limit should be interpolated using data at higher concentrations because the OMs requires solute concentration over 0.1 mol/$\ell$ and interactions between solutes modify the values of D [3, 19]. MR imaging can determine the exact D of CAs of ppm concentration without being affected by the concentration, because MR imaging achieves a sensitivity 100–1000 times higher than that of OMs, where CAs are compounds that bind to paramagnetic ions [20, 21]. When the movement of the CA diffusing from the inside of the blood tube to the surrounding lesion tissue is measured by MRI, the $resD$ of the CA in the tissue is exactly determined because the clinical dose of the CAs is 0.1–0.5 mmol/$\ell$. The $resD$ of the CA can be converted to the $resD_{\text{self}}$ of water in the lesion tissue using the ratio among molecular sizes of the CA and water, and apparent pore size of the tissue [22]. Although the $resD_{\text{self}}$ of water in tissues is determined only in the direction perpendicular to the MR imaging slice, the $resD$ of the CA can be determined for any direction. Thus, the diagnosis based on the indirect observation of the $resD_{\text{self}}$ of water converted from $resD$ of the CA in MR imaging of living materials can improve the accuracy of the diagnosis based on the direct observation of $resD_{\text{self}}$ of water in tissue.

The inaccurate temperature dependence in calculating the radius of the water molecule using the SEE will lead to the inaccuracy in evaluating material void structures having water content because the Stokes radius is the basic scale for measuring the void space of materials. The radii of $H_2O$ and $D_2O$ molecules can be determined by RBM that occurs simultaneously with the TBM using the DRF based on the previously conducted measurements of the dielectric relaxation time [23, 24] and viscosity [25, 26]. The radius of water molecules regarded as spheres in the vapour state can be calculated from the van der Waals b constant [25, 27, 28]. The thermal expansion of the space occupied by one liquid water molecule can be calculated using the density change with temperature [25]. This study, therefore, aims to compare the sphere radii and its temperature dependences of liquid water, calculated using the DRF van der Waals b constant, density, and SEE, in order to examine the inaccurate temperature dependence of the SEE.

**Theory**

A water sphere of radius and mass M is considered. The mass M of one water molecule is $M = 18m_p$ where $m_p$ is the proton mass ($1.67 \times 10^{-27}$ kg). The distance between the hydrogen and oxygen nuclei $r_{\text{OH}}$ is 0.9575 Å and the HOH angle $\theta_{\text{HOH}}$ is 104.45°. The x-y plane involving two hydrogen's and oxygen is shown in Figure 1(a), where the z-axis is vertically oriented. The Centre of gravity of the water molecule exists approximately at the Centre of the oxygen nucleus, and the two hydrogen atoms (protons) rotate around the oxygen nucleus. The three moments of inertial $I_x$, $I_y$, and $I_z$ along the x, y, and z-rotation axes, are considered in Figure 1(b-d), respectively. Using these assumptions, $I_z = 2m_p r_{\text{OH}}^2$. The straight line connecting the two hydrogens is indicated by $r_{\text{OH}}$ and the distance between the oxygen nucleus and the centre of $r_{\text{OH}}$ is $r_{\text{OH}}^2$ where $r_{\text{OH}} = 1.51 + 2r_{\text{OH}} \cdot \sin(104.45^\circ/2)$ and $r_{\text{OH}} = 0.586 + 2r_{\text{OH}} \cdot \cos(104.45^\circ/2)$. Thus, $I_x = 2m_p r_{\text{OH}}^2$ and $I_y = 2m_p (r_{\text{OH}}/2)^2$ and $I_z = 2m_p (r_{\text{OH}}/2)^2$. The average $I = \left( I_x + I_y + I_z \right)/3$ of $I_x$, $I_y$, and $I_z$.

is assumed to be the moment of inertia for the water sphere rotation as

2 4 3 $$ I = \frac {4}{3} m _ {p} r _ {o H} ^ {2} \tag {2.1} $$

Click to enlarge

Figure 1(a): Locations of two hydrogen’s and one oxygen in water molecule. Rotations of the water sphere (electron cloud) along (b) x-, (c) y-, and (d) z-axes around the rotation axes passing through the oxygen nuclei (centre of gravity).

Where the factor 4/3 is derived from ( ) ( ) ( )

2 2 2 2sin 104.45 / 2 2cos 104.45 / 2 / 3 ° ° + +

(2+2sin2(104.45°/2) + 2cos2(104.45°/2))/3 as shown in Table 1.

Because the hydrogen and oxygen atoms are positively and negatively charged, respectively, the water molecule forms an electric dipole moment pH2O. Because the dipole consists of one positive charge and one negative charge separated by a dipole length rD, it is assumed that the positive charges of the two hydrogens are concentrated into single hydrogen and that rD is equal to the distance rOH between the hydrogen and oxygen nucleus. Fractional atomic charges of qO = −0.3990e and qH = +0.3990e are allocated to the oxygen and hydrogen nuclei, respectively, when constructing the dipole pH2O, where e is the elementary charge (1.602×10−19 C). Thus, the dipole pH2O is determined to be pH2O = (0.3821 Å) e [10, 29]. Although an electric field is applied on the dipole to artificially change the molecular rotation in the dielectric relaxation measurement, the electrically modified rotation is negligibly lower than the thermal rotation as shown in Section 3.

In accordance with the equipartition law of energy, the average energy of kBT /2 is assigned to each degree of rotational and translational freedom of the water sphere, as expressed by Eqs. (2.2a) and (2.2b), respectively, where T is the temperature in Kelvin (K) and kB is the Boltzmann constant (1.38×10−23 J/K) [9].

2 1 1 (2.2.a) 2 2

B dx M k T dt   =    

2 1 1 (2.2. ) 2 2

$$ \frac {1}{2} I \left\langle \left(\frac {d \theta}{d t}\right) ^ {2} \right\rangle = \frac {1}{2} k _ {B} T (2. 2. b) $$ where, t, x, and θ are the time, translational and rotational displacements, respectively, and (1/2)M<(dx/ dt)2 > and (1/2)I<(dθ/ dt)2> are the time-averaged translational and rotational energies, respectively. The average thermal velocity Vth = <dx/dt> and angular velocity Ωth = <dθ/dt> at 20 ℃ are calculated to be Vth = 367 m/s (=(kBT/M)1/2) and Ωth

Nanomedicine & Nanotechnology Open Access

$=1.41 \times 10 \text{ rad/s} = (k_B T/I)^{1/2}$. respectively. Assuming that $a_w = 1.44 \text{ cm}^2, 10,13$ the thermal rotation velocity $V_{th}$, on the sphere surface calculated using $\Omega_{th} = 2027 \text{ m/s} = \Omega_{th} \cdot a_w$, which is proportional to $(M/2m_B)^{1/2}$ and 5.5 times $V_{th}$. The centrifugal force $F_H$ acting on the rotating two hydrogen nuclei is approximately given as $F_H = 2k_B T/r_{OH}$ because $F_H$ is calculated to be $2m_B V_{th} s^2/r_{OH}$. Irrespective of MW, the same amount of energy $k_B T$ is assigned to the rotational energy around one rotation axis according to Eq. (2.2b). The centrifugal force $F_H$ causes the gyro effect that keeps the same direction of the motion.

Consider a water sphere of radius $a_w$ and perform a rotational motion with rotational velocity $\theta/dt$ in a Newtonian fluid of liquid water, of which viscosity is $\eta$. The rotational motion of the water sphere carrying out a random walk in the rotational direction is called rotational Brownian motion (RBM) [4, 7, 8, 9]. Because the force couple for the rotational motion is $8\pi a_w \eta(d\theta/dt)$, $8\pi a_w^3 \eta(d\theta/dt)$, the rotational motion of the water sphere is described by the Navier–Stokes equation using Eq. (2.1), which is a torque equation as [8, 9, 10]

$$I \frac{d^2\theta}{dt^2} = -8\pi a_w^3 \eta \frac{d\theta}{dt} + F_\theta(t) a_w$$

(2.3)

Where $F_\theta(t) a_w$ is an impulsive torque arising from the thermal agitation. By multiplying both sides of Eq. (2.3) by $\theta$, Eq. (2.3) is transformed into Eq. (2.4):

$$\frac{I}{2} \frac{d^2(\theta^2)}{dt^2} - I \left(\frac{d\theta}{dt}\right)^2 = -\frac{8\pi a_w^3}{2} \frac{d(\theta^2)}{dt} + \theta F_\theta(t) a_w$$

(2.4)

Where $2\theta(d^2\theta/dt^2) = d^2(\theta^2)/dt^2 - 2(d\theta/dt)^2$ is used. Taking the time average of Eq. (2.4) and using the equipartition law of Eq. (2.2b), we obtain

$$\frac{I}{2} \frac{d^2(\theta^2)}{dt^2} + \frac{8\pi a_w^3}{2} \frac{d(\theta^2)}{dt} = k_B T + \theta F_\theta(t) a_w$$

(2.5)

Where terms in brackets $<>$ mean time-averaged quantities. Because $F_\theta(t)$ and $\theta$ independently vary with time and $F_\theta(t)$ is caused by random collisions, we obtain $<\theta F_\theta(t) a_w> = <\theta><F_\theta(t)> a_w$, where $<F_\theta(t)> = 0$. Thus, $<\theta F_\theta(t) a_w>$ in Eq. (2.5) is eliminated by time averaging. Therefore, the solution of Eq. (2.5) is

$$\frac{d(\theta^2)}{dt} = \frac{2k_B T}{8\pi a_w \eta} + Ce^{-(t/\tau)} \tau_p = \frac{1}{8\pi a_w^3}$$

(2.6)

Where $C$ is a constant of integration. The inspection of Eq. (2.3) gives $r_p$ the time step of one rotational random walk as $\tau_p = 1/(8\pi a_w^3)$. The last term $C\exp(-t/\tau_p)$ in Eq. (2.6) disappears for a long timescale because $\tau_p$ is of femtosecond order. Thus, the cumulative effect of the rotational random walk $<\theta^2>$ derived from Eq. (2.6) leads to the dielectric relaxation formula (DRF) as

$$\langle \theta^2 \rangle = 2D_{\text{rot}} t, D_{\text{rot}} = \frac{k_B T}{8\pi a_w^3}, \text{ and } \tau_{\text{rel}} = \frac{4\pi a_w^3}{k_B T},$$

(2.7)

Where $D_{\text{rot}}$ is called the rotational diffusion coefficient. The time required for the rotation to change to an entirely new state is defined as the dielectric relaxation time $\tau_{\text{rel}} = 4\pi a_w^3 / k_B T$ by setting $<\theta^2> = 1$.

Consider a water sphere of radius $a_w$ and mass $M$, and perform a translational motion in the x-direction with velocity $dx/dt$ in a Newtonian fluid with viscosity $\eta$. The translational motion of the water sphere carrying out a random walk due to the thermal agitation is called translational Brownian motion [3, 4, 6, 7]. Stokes' law gives the resistive drag (RD) for the translational motion as $6\pi a_w \eta(dx/dt)$ [1, 2]; thus, the translational motion of the water sphere is described by the Navier–Stokes equation as: [9, 10]

$$M \frac{d^2x}{dt^2} = -6\pi a_w \eta \frac{dx}{dt} + F_x(t),$$

(2.8)

Where $F_x(t)$ is time and a impulsive force arising from random collisions, respectively. Using Eq. (2.1), the solution of Eq. (2.8) is derived as

$$\frac{d\left(\langle x^2 \rangle\right)}{dt} = \frac{2k_B T}{6\pi a_w \eta} + Ce^{-(t/\tau_w)} \tau_w = \frac{M}{6\pi a_w \eta}$$

(2.9)

Where $C$ is a constant of integration. The inspection of Eq. (2.8) gives $r_p$ the time step of one translational random walk as $\tau_p = M/(6\pi a_w)$. The last term $C\exp(-t/\tau_p)$ in Eq. (2.9) disappears for a long timescale because $\tau_p$ is of femtosecond order. Thus, the cumulative effect of the translational random walk $<x^2>$ in Eq. (2.9) leads to the translational diffusion described by the Stokes–Einstein equation (SEE):

$$\langle x^2 \rangle = 2D_t D = \frac{k_B T}{6\pi a_w}$$

(2.10)

Where $D$ is the diffusion coefficient of the translational Brownian motion.

The RD in the SEE [6πa_wη(dx/dt)] and the force couple in the RDF [8πa_w³η(dθ/dt)] are approximately equivalent, because RBM can be regarded as small particles carrying out random walks on a molecular surface being affected by the RD in a manner similar to Stokes' law used in the SEE. Thus, the factors 6πa_wη(dx/dt)] in the denominators of the SEE and DRF, respectively, are also referred to as the RD. The difference between [6πa_wη(dx/dt)] in TBM and [8πa_w³η(dθ/dt)] in RBM is that [6πa_wη(dx/dt)] has two components of the viscous drag: [4πa_wη(dx/dt)] and pressure force: [4πa_wη(dx/dt)] while [8πa_w³η(dθ/dt)] has only a single component of the viscous drag.1

The translational displacement $x_{tr}$ for one translational random walk time step $\tau_w$ is $x_{tra} = V_{th} \cdot \tau_w$. Because the repetition number $N$ of the random walk after time $t$ is given as $N = t/\tau_w$, N repetitions with random displacement $x_{tr}$ lead to an average displacement of $<x^2> = N < x_{tra}^2 > (= tV_{th}^2\tau_w)$, which is expressed as

$$\langle x^2 \rangle = \frac{k_B T}{b_C a} \dot{\sigma}_w t, \dot{\sigma}_w = \frac{M}{6 w} . \tag{2.11}$$

Thus, we obtain $<x^2> = D_{trans} t$, where $D = k_B T/6\pi a$, which is similar to Eq. (2.6). Therefore, except for the numeric factor of 2, the SEE can be derived approximately without solving Eq. (2.2). Similarly, the angle displacement $\delta$ for one rotational random walk duration $\tau_p$ is $\delta = \Omega_{th} \cdot \tau_p$. Because the repetition number $N$ of the rotational random walk after time $t$ is given as $N = t/\tau_p$, N repetitions with random displacement $\delta$ lead to an average angle displacement of $<\theta^2> = N < \delta^2> (= t\Omega_{th}\tau_p)$, which is expressed as

$$\langle \theta^2 \rangle = \frac{k_B T}{b_C a} \dot{\sigma}_w t, \dot{\sigma}_w = \frac{I}{8 w^3} . \tag{2.12}$$

Thus, we obtain $<\theta^2> = D_{rot} t$, where $D_{rot} = k_B T/8\pi a^3\nu$, which is similar to Eq. (2.7). Therefore, except for the numeric factor of 2, the DRF can be derived approximately without solving Eq. (2.3).

Because the time steps $\tau_p$ and $\tau_w$ of the translational and rotational random walks $\tau_p$ and $\tau_w$ are calculated to be $\tau_p = 0.271$ fs and $\tau_w = 11.1$ fs at 20 C, respectively. The ratio $\tau_w/\tau_p$ is 41, which is proportional to the mass ratio $M/m_p$ (=18) and does not depend on $T$. The translational Brownian motion turns the direction every 41 rotations because $\tau_w = 41:1$. The kinetic energies of the molecule performing TBM and RBM are indicated by $E_{trans}$ and $E_{rot}$, respectively.

Because the stride of one translational random walk is $V_{th} \cdot \tau_w$, and RD is $6\pi a_w\nu V_{th} (= M \cdot V_{th}/\tau_w)$ [1, 2] the energy consumed per one time step $w$ of TBM is $k_B T (= V_{th}^2 \cdot M)$. Because the angle displacement of one rotational random walk is $\Omega_{th} \cdot \tau_p$ and force couple is $8\pi a_w^3\nu \Omega_{th} (= I \cdot \Omega_{th}/\tau_p)$, the energy consumed per one time step $\tau_p$ of RBM is $k_B T (= \Omega_{th}^2 \cdot I)$. Thus, the $E_{trans}$ and $E_{rot}$ have the maximum energies of $E_{trans,max} = E_{rot,max} = k_B T$ at the start of the random walk of $t = 0$ and decreases monotonically to the minimum energies of $E_{trans,min} = E_{rot,min} = 0$ at the end of one random walk of $t = \tau_w$ and $\tau_p$, respectively. Despite the monotonic decrease of $E_{rot}$ during $\tau_p$, the rotational random walk consumes 41 times more energy than translational random walk during a single translational random walk time step $\tau_w$.

Sphere Radii of $H_2O$ and $D_2O$ Determined from Dielectric Relaxation Time

When the volumetric radius of the water sphere is assumed to be $a_{vol}$, the volume of the water sphere is given by $4\pi a_{vol}^3/3$. The number $N$ of water spheres existing in 1.0 m³ is $1/(4\pi a_{vol}^3/3)$, which is equivalent to the density $\rho$ divided by the mass of one molecule. Thus, the sphere radii $H_{vol}$ and $D_{vol}$ of $H_2O$ and $D_2O$ are calculated from $1/(4\pi H_{vol}^3/3) = H\rho/18m_p$ and $1/(4\pi D_{vol}^3/3) = D\rho/20m_p$, where $H\rho$ and $D\rho$ are the liquid densities of $H_2O$ and $D_2O$, respectively. The $H_{vol}$ and $D_{vol}$ as functions of $T$ in $^1\text{C}$ at 1 atm are shown on the right side in Tables 2-5, respectively, where the decrease of $H\rho$ and $D\rho$ with $T$ and increase of $H_{vol}$ and $D_{vol}$ with $T$ are recognized. The increases of $H_{vol}$ and $D_{vol}$ with $T$ can be regarded as the thermal expansion of the sphere volume served for the rotations of $H_2O$ and $D_2O$ molecules although the molecular radius determined by the electron cloud does not expand with $T$. Because $H\rho$ and $D\rho$ take their maximums exactly at 3.98 °C and at 11.6°C, respectively, the maximum densities of $H_{vol}$ and $D_{vol}$ are approximately set to be $H_{vol}$ at 0 °C and $D_{vol}$ at 10 °C, respectively. The minimum volumetric radii of $H_{vol,min}$ and $D_{vol,min}$ are set to be $H_{vol,min}$ at 1.9253 Å at 0 °C and $D_{vol,min}$ at 1.9282 Å at 10 °C, respectively. The thermal expansion rates of the volumetric radii $H_{vol,min}$ and $D_{vol,min}$ are defined as $(H_{vol}/\text{vol,min})$ and $(H_{vol}/\text{vol,min})$, which are calculated from $(H_{vol}/\text{max,})$ and $(H_{vol}/\text{max,})$ respectively. The rates of $(H_{vol}/\text{max,})$ and $(H_{vol}/\text{max,})$ as functions of $T$ are shown in Tables 2-5 and Figure 2-5. Although $(H_{vol}/\text{max,})$ and $(H_{vol}/\text{max,})$ are not exactly proportional to $T$, the thermal expansion rates vol of $H_2O$ from 0 to 50°C and $D_2O$ from 10 to 50°C are calculated to be vol = 7.9×10^-5 °C. The calculation based on the hexagonally close-packed $H_2O$ sphere yields that the $H_2O$ radius is 1.74 Å.13 because the water sphere is not close-packed, the $H_2O$ volume is greater than the sphere radius having the degree of rotational freedom for RBM is smaller than $a_{vol}$ and $a_{hes}$ which will be determined later.

** ( )

1 3 H O H O H H 2 w 2 w min max a a 1 ñ ñ 1

$$ \left[ \mathrm {^ {H} _ {2} ^ {O} \tilde {n} _ {w}} / \mathrm {^ {H} _ {2} ^ {O} \tilde {n} _ {w , \min }} 1 - 1 \right] / \left[ \left(\mathrm {^ {H} _ {\max }} / \mathrm {^ {H}}\right) ^ {1 / 3} - \right] $$ /

Click to enlarge

Click to enlarge

Click to enlarge

Click to enlarge

The van der Waals b constant is determined from b = RTc/8Pc, where R (= NAkB), NA, kB, Tc, and Pc are the gas constant (8.3145 J/(K・mol)), Avogadro number (6.02214×1023 /mol), critical temperature (K), and critical pressure (Pa), respectively [25, 26, 27]. Because Tc, and Pc are 647.3 K and 22.12 × 106 Pa (= 218.3 atm) for H2O, and 643.89 K and 21.66 × 106 Pa (= 213.7 atm) for D2O, bs of H2O and D2O are calculated to be 3.041×10-5 m3/mol and 3.090×10-

5 m3/mol, respectively. Thus, the radii H 2 Oaw b and D 2 Oaw b of H2O and D2O in the vapour state are calculated to be H2Oaw b = 1.445Å and D2Oaw b = 1.453Å, using NA(1/2)(4π/3)(2aw)3 = b [28]. The most accurate radii H2Oaw b and D2Oaw b of H2O and D2O molecules, which are regarded as rotating spheres were determined with four-digit accuracy in the aqueous vapour state by the van der Waals b constant, where D2Oaw b was greater than H2Oaw b by 5.5×10-3. The radii H2Oaw b and D2Oaw b will be the standards in the evaluation of H2O and D2O radii in the liquid state.

The dielectric relaxation time τrel of a polarised molecule such as a water molecule is measured by locating a molecule in an electric condenser with an alternating electric field of frequency f. The capacity of the condenser decreases above a critical frequency fcr= 1/τrel because the rotational motion of the electric dipole cannot respond to a high-frequency alternating field. Thus, the dependence of the capacity on f determines τrel. Because τrel is measured by applying an alternative electric potential difference of 0.1V on the two electrodes surrounding the 30-μm-thick liquid cell that matches the THz band wave-length, the applied field Erel is Erel= 3×103 V/m. If the maximum electric field Emax without causing chemical reactions is assumed to be Emax = 109 V/m (= 100 mV/Å), the applied Erel will not induce chemical reactions. Because the electric force acting on the hydrogens rotating around the oxygen nucleus is qHErel, the acceleration for the velocity vH of the hydrogen by the force qHErel is qHErel /mp. Thus, vH reaches the maximum rotation velocity VH,max =16 μm/s [=(qHErel/ mp)・(τp/2)] for the half of one rotational random walk time step τp. Because VH,max is as low as 7.7×10-9 of the average rotational velocity Vth,s = 2027 m/s at 20℃, the applied field Erel does not affect the accuracy of the τrel measurement.

The molecular sphere radii H2Oaw of H2O and D2Oaw of D2O are calculated by substituting the measured values of τrel, η, and T of H2O and D2O into the DRF. Respectively. The τrel [14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24] and η[25] of H2O as functions of T are shown in Tables 2 and 3, and τrel [14, 15, 16, 17, 18, 19, 20, 21, 22, 23] and η[25, 26] of D2O are shown in Table 4. The D2O measurement was performed at T ≧5℃ because the melting point (m.p.) of D2O is 3.81 ℃. There were two τrel measurements for H2O in 1948 (Table 2) [23] and in 1972 (Table 3) [24], and one measurement for D2O in 1948 (Table 4) [23]. The sphere radii H2Oaw and D2Oaw of H2O and D2O calculated using the DRF are shown in Tables 2,3, Figs. 2,3, and Table 4, Fig. 4, respectively. The minimum radii H2Oaw,min and D2Oaw,min of H2O and D2O are calculated as H2Oaw,min = 1.44±0.01 Å at 0℃ and D2Oaw,min = 1.45±0.01 Å at 10℃ because Hρmax and Dρmax are defined at 0 and 10℃, respectively. Because there are temperature points at which the radii change by 0.01 Å with 10℃ increment in the fluctuating curves in Figs. 3 and 4, the error width in calculating H2Oaw,min and D2Oaw,min was determined to be ±0.01 Å. The radius expansion rates of the radii H2Oaw and D2Oaw are defined as (H2Oaw / H2Oaw,min) and (D2Oaw / D2Oaw,min), respectively. The rates (H2Oaw / H2Oaw,min) and (D2Oaw / D2Oaw,min) as functions of T are shown in Tables 2,3, Figs. 2,3, and Table 4, Fig. 4, respectively. Although (H2Oaw/ H2Oaw,min) and (D2Oaw/D2Oaw,min) are not exactly proportional to T, the radius expansion rates rot of H2O from 0 to 50℃ and D2O from 10 to 50℃ are determined to be rot = (3.0±0.6)×10-

4 /℃, of which error width 0.6×10-4 /℃ is determined from the fluctuated curves in Figurs 2-4. There was not sufficient accuracy for the τrel data to discriminate the difference of the radius and radius expansion rate between H2O and D2O.

The radius expansion rate calculated from the DRF is greater than the thermal expansion rate calculated from the density as shown in Tables 2-4 and Figs. 2-4. Thus, the ratios of the radius expansion to thermal expansion of H2O and D2O

are defined by $[H_{20}a_w / H_{20}a_w_{\min} - 1] / [(H\rho_{\max} / H\rho)^{1/3} - 1]$ and $[D_{20}a_w / D_{20}a_w_{\min} - 1] / [(H\rho_{\max} / H\rho)^{1/3} - 1]$, respectively. These ratios are shown at the centre in Tables 2-4, where they cannot be defined for $H_2O$ at $0^\circ$ and for $D_2O$ at $10^\circ$. Although the ratios are fluctuating because the curves in Figs. 2-4 are fluctuating, the rates are almost converged to stable values of 3.53 and 3.11 at the highest trel measurement temperatures of $75^\circC$ for $H_2O$ in Figures 2 and 3, respectively, and that of 3.94 at $60^\circC$ for $D_2O$ in Figure 4. These ratios mean that the radius expansion with temperature for $H_2O$ and $D_2O$ calculated using the DRF is about four times greater than the thermal expansion calculated using the density.

Because $\tau_{rel}$ is 9.55 ps at $20^\circ$, the ratio $\tau_{rel} : \tau_w : \tau_p$ is calculated to be 35000:41:1 at $20^\circC$. The ratio means that there are sufficient number of rotations to obtain the stable statistical average during one dielectric relaxation because $\tau_{rel} : \tau_p = 35000:1$. The translational random walk changes the direction every 41 rotations because $\tau_w : \tau_p = 41:1$. The solvent viscosity mainly affects the accuracy in calculating the molecular radius using the DRF. If the viscosities of $H_2O$ and $D_2O$ at the maximum density temperatures are determined with three- to four-digit accuracy, the calculation using the DRF can discriminate the difference of the sphere radii between $H_2O$ and $D_2O$ in the liquid state because the van der Waals b constant determined that $D_{20}a_w$ was greater than $H_{20}a_w_b$ by $5.5 \times 10^{-3}$.

The Stokes radius $H_{20}a$ of $H_2O$ is calculated by substituting the measured values of $D$, $\eta$, and $T$ of $H_2O$ into the SEE. The values of $D^{30}$ and $\eta^{25}$ of $H_2O$ from 5.29°C to 50°C are shown in Table 5. The Stokes radius $H_{20}a$ calculated using the SEE is shown in Table 5 and Figure 5. The $D$ of $H_2O$ was measured by tracking the tracer $H_{20}O$ as solute moving in $H_2O$ as solvent [30]. Although tracer tracking cannot measure selfD, the obtained $D$ of $H_{20}18O$ in $H_2O$ is regarded as the selfD of $H_2O$. The minimum Stokes radius $H_{20}a$ is 1.025 Å at 5.29°C. The radius expansion rate of $(H_{20}a / H_{20}a_{\min})$ as a function of $T$ is shown in Tables 5. Although $(H_{20}a / H_{20}a_{\min})$ is not exactly proportional to $T$, the Stokes radius expansion rate $\Delta_{trans}$ of $H_2O$ from 5.29 to 50°C is calculated to be $\Delta_{trans} = 2.0 \times 10^{-3} / \circC$. The Stokes radius expansion rate calculated using the SEE is greater than the thermal expansion rate calculated from the density as shown in Table 5 and Figure 5. The ratio of the Stokes radius expansion to thermal expansion of $H_2O$ defined by $[H_{20}a / H_{20}a_{\min} - 1] / [(H\rho_{\max} / H\rho)^{1/3} - 1]$ is shown at the centre in Table 5, where they cannot be defined at 5.29°C. Although it takes an extraordinarily greater value of 113 at 15.01°C, the ratio converges to 22.7 at the highest D measurement temperature of 50°C. The ratio means that the radius expansion with temperature calculated using the SEE is 23 times greater than the thermal expansion calculated using the density.

Because the viscosities $\eta$ of $H_2O$ and $D_2O$ are determined in increments of 10$^\circ$ [25, 26], the $\eta$ at other temperature points should be estimated, where the lowest measurement temperature of the $\eta$ of $D_2O$ is 3.82°C. The two viscosities of $H_2O$ (or $D_2O$) measured at lower $T_{low}$ and higher $T_{high}$ temperatures are denoted by $\eta_{low}$ and $\eta_{high}$, respectively. When the temperature difference between $T_{low}$ and $T_{high}$ is within 10°C, $\eta_{low}$ and $\eta_{high}$ are described using similar two parameters of $A$ and $E$ as

$$\epsilon_{low} = A \exp \left( - \frac{E}{k_B T_{low}} \right) \quad (3.1a)$$

$$\epsilon_{high} = A \exp \left( - \frac{E}{k_B T_{high}} \right) \quad (3.1b)$$

Because $A$ and $E$ are determined from Eqs. (3.1a) and (3.1b), $\eta$ at the intermediate temperature $T(T_{low} \leq T \leq T_{high})$ is calculated from $\eta = A \exp(-E/k_B T)$. The parameter $E$ is called the activation energy that was known to be almost constant within a temperature interval of 10$^\circ$. Because $\eta$ of D20 at 5$^\circ$ in Table 4 and $\eta$ of $H_2O$ at 5.29, 15.01, 25.00, and 39.98$^\circ$ in Table 5 are estimated using Eq. (3.1), and the curves showing the temperature dependence of the radius as shown in Figs. 2-4 are fluctuating, the expansion rates of $\Delta_{rot}$ and $\Delta_{trans}$ were determined with two digit accuracy.

There are three radius expansion rates of $\Delta_{vol} \Delta_{rot}$ and $\Delta_{trans}$ caused by temperature increase, where $\Delta_{vol} = 7.9 \times 10^{-5} / \circC$ is the thermal expansion rate determined by the density, $\Delta_{rot} = 3.0 \times 10^{-4} / \circ$ is the radius expansion rate determined by $\tau_{rot}$ and $\Delta_{trans} = 2.0 \times 10^{-3} / \circ$ is the Stokes radius expansion rate determined by $D$. The ratio among the three rates is approximately described as $\Delta_{rot} \Delta_{rot} : \Delta_{trans} = 1:4:23$. Although TBM and RBM are occurred simultaneously, an essential difference between the SEE and DRF was found because $\Delta_{trans}$ is six times greater than $\Delta_{rot}$.

Water Sphere Radii Performing Rotational Brownian Motion During Cluster Formation

Locating a uniform medium of an air, liquid, or solid in an electric capacitor applied by dc or alternating electric field with less than 1-kHz frequency, the dielectric ratio $er$ per mol of the molecule in the medium is determined. The adoption of 1-kHz alternating field is to avoid the cohesion of the molecule into the electrode. Based on $\epsilon_e$ the dipole moment of the molecule in the medium can be determined [8]. The similar $\epsilon_e$ per mol is obtained in both liquid and vapour states when the molecule has no correlations and associations. Thus, most molecules exhibit similar dipole moments in liquid and vapour states. However, the dipole moment of the water molecule in liquid state is about twice that in vapour state. When oxygen is placed at the centre of the tetrahedron, four atomic bonds can be made toward the four apices of the tetrahedron. Two hydrogens or two deuteriums are bound to two of the four apices in H2O and D2O, respectively, and the remaining two apexes create two hydrogen bonds using unpaired electrons. Thus, the hydrogen-bonded cluster model composed by five water molecules in the liquid state was proposed, where four oxygens and one oxygen locate at the four vertices and one centre of the tetrahedron, respectively [31, 32]. Because the hydrogen bonding is created by a hydrogen existing between two oxygens, the locations of the ten hydrogens in the tetrahedron under the restriction of the hydrogen bonding create the correlation among the water dipole moments. Because the discrepancy of the water dipole moments between the liquid and vapour states was explained by the correlation, the existence of the hydrogen- bonded cluster is accepted. The five oxygens locations constituting the tetrahedron cluster were confirmed by the X-ray scattering of liquid water [14].

The volumetric molar heat capacity Cv of a gas is determined by the total number of degrees of motional freedom N_f_ and is expressed as Cv = (N_f_ /2)R. The possibility of translational motion along the x-, y-, and z-axes implies three degrees of translational freedom (N_f_ = 3) for monatomic gases. Because of the three possible directions of the rotational axis, the x-, y-, and z-axes, imply three additional degrees of rotational freedom (giving a total of N_f_ = 6) for three-atom molecules such as water molecules, the isovolumic molar heat capacity of aqueous vapour (H2O gas) is Cv ≒ 6(R/2), which implies six degrees of motional freedom. Because the water sphere is regarded to be a perfect sphere similar to monatomic gases such as He, the three degrees of rotational freedom for the rotating water sphere is inconsistent. However, the experimentally confirmed Cv of H2O vapour assures the validity of Eq. (2.2) and the three degrees of rotational freedom of H2O vapour. The three degrees of rotational freedom are also expected to be conserved in a liquid water molecule because the molar heat capacity of water is approximately 18.2(R/2) from 0 to 100 °C at 1 atm and the degrees of motional freedom N_f_ of liquid water is 18.2 (> 6). The appropriateness of H2Oaw and D2Oaw as rotating sphere radii was supported by the fact that the sphere radii H2Oaw and D2Oaw determined by τrel are similar to the radii H2Oaw b and D2Oaw b determined by the van der Waals b constant, and lower than the volumetric sphere radii H2Oavol and D2Oavol by 25%.

The existence of the hydrogen-bonded cluster, that is, some type of solid nuclei remaining in the liquid state above freezing point is also supported by the smaller entropy generated by the solid-liquid transition of water. The densities of H2O ice and D2O ice are about 10% less than those of H2O liquid and D2O liquid. The fact that the maximum density temperature of H2O liquid and D2O liquid exists above the m.p. is explained by the fact the ice nuclei (hydrogen-bonded clusters) that lowers the density of liquid water remains at temperatures above m.p. [14]. There are two contradicting phenomena that the residual ice nuclei melts and the liquid density increases with temperature, and that the liquid density decreases with temperature due to thermal expansion. Thus, the maximum density temperature exists above m.p. by the remaining ice nuclei and thermal expansion. The part of the excess freedom over six ∆N_f_ = 12.2 (= 18.2 – 6) is expected to be related to the rotation of the hydrogen-bonded cluster [10]. The radius of a water molecule estimated from τrel from the m.p. to 60℃ was almost similar to the electron cloud radius of a single water molecule,[14] but not of that of the water cluster, which has been proposed to exist in super cooled liquid [33]. The measurements of εr and τrel are conducted at frequencies of less than kHz and THz, respectively. Thus, the water molecule as a component of a hydrogen-bonded cluster in the liquid state was considered to rotate as a single water molecule in the vapour state within the picosecond timescale of τrel, while the hydrogen-bonded cluster has an averaged timescale much larger than τrel. Although the spin-lattice (T1) and spin-spin(T2) relaxation time scales of the NMR is the second timescale, T1 is reasonably evaluated based on the single water molecule radius [34].

Effect of Rotational Brownian Motion on Translational Brownian Motion

The Stokes radius H2Oamin of H2O is H2Oamin = 1.025 Å at 5.29℃, as shown in Table 5. The inaccuracy of the SEE is pointed out because H2Oamin = 1.025 Å is smaller than the electron cloud14 by as much as 29 % [12, 13]. When a sphere of radius a is immersed in fluid, the RD required for the sphere to move with a steady velocity dx/dt is 6πaη(dx/dt) according to the Stokes law [1, 2]. The factor 6πaη in the denominator of the SEE comes from 6πaη(dx/dt). To increase the Stokes radius of H2O, it is proposed that the factor 6 in the SEE should be changed into a factor between 4 and 5; that is, the RD should be reduced. The inaccuracy of the SEE highlights that the Stokes radius of lower MW molecules such as water is too small when the diffusion coefficient of the low MW molecule as a solute is measured in an aqueous solution.11 The reduction in the RD is explained by the slipping condition, in which the solute molecule can easily slip through the gap between the solvent molecules when the size of the gap is compatible to that of the solute molecule.

If the factor 6 in the SEE is changed into 4.25, the Stokes radius of H2O at 5.29 ⃘C can become 1.445Å. Thus, it is assumed that there are the active RD and inactive RD regions, where the sphere surface receives the RD and does not receive RD, respectively, and the area ratio Γ of the inactive RD region to the entire sphere surface is given by 0.292 [= (6 - 4.25) / 6]. This means that the SEE can yield the reasonable Stokes radius for H2O if the surrounding solvent water molecules multiplied by Γ do not contribute to the RD. The water sphere performing the Brownian motion as the solute molecule is called the centre sphere, and the water spheres surrounding the centre sphere are the solvent molecules and called the surrounding spheres. The directional axis is defined along the translational motion of the centre sphere. The cross and vertical sections are defined by planes perpendicular and parallel to the directional axis, respectively. The azimuthal angle φspr: 0° ≤ φspr ≤ 360°and polar angle θspr: 0°≤θspr ≤ 180°are measured in the cross and vertical sections, respectively. The cross section is shown at the centre in Figure 6, where the directional axis is perpendicular to the paper and the centre sphere and six surrounding spheres are displayed. The circumference of the centre sphere is divided into two rubbing laminar (active RD) regions and two suction groove (inactive RD) regions, which are related to the energy transfer (consumption and supply) to the translational and rotational random walks, respectively. The angle widths of the rubbing laminar φspr,drg and suction groove φspr,pls regions are φspr,drg = 127.5°and φspr,pls = 52.5°, where 127.5°and 52.5°are derived from 180°×(1-Γ) and 180°×Γ, respectively. The azimuthal angles φspr covering the rubbing laminar and suction groove regions are 0° ≤ φspr ≤ φspr,drg and 180° ≤ φspr ≤ (180° + φspr,drg ), and 127.5° ≤ φspr ≤ (127.5° + φspr,pls ) and (180° + 127.5° ) ≤ φspr ≤ (180° + 127.5° + φspr,pls ), respectively. Four water spheres for decelerating the centre sphere as the RD and two water spheres for inducing the rotation of the centre sphere are located on the rubbing laminar and suction groove regions, respectively. The division between the two regions depends on only φspr in the cross section and not on θspr in the vertical section.

Click to enlarge

Because the Stokes law assumes uniform laminar flow around the molecule, the uniform laminar flow cannot produce molecular rotation. Because the surface rotation velocity Vth,s is 5.5 times greater than the translational velocity Vth, the molecular rotation cannot reach the necessary surface velocity Vth,s even if the molecular rotation is induced by the directional change occurred between the two translational random walk strides with velocity Vth. It is difficult for the surrounding shear flow of which translational motion energy is kBT to give the molecule performing TBM the rotational motion energy kBT 41 times during a single translational random walk time step τw. The thermal energy is distributed to the translational and rotational motion freedom according to the equi-partition law in Eq. (2.2). Because the specific heat ensures the sufficient rotational freedoms in the liquid state as discussed in Section 4, the rotational energy kBT should be recovered 41 times during τw, soon after the termination of the rotation. Thus, there should exist the suction groove region, where the surrounding spheres give only the rotational impulse to the centre sphere and not give the RD. The 41 times repetition of replenishing the rotational freedom with energy during one time step τw can be regarded as the increase of the number of the state and entropy S. One translational random walk starts when the Helmholtz free energy F = U- TS takes its local extreme due to the thermal agitation, where U is the internal energy corresponding to Etrans and Erot. The free energy F decreases during a single time step τw, and recovers the local extreme as the new start of the random walk after τw. The translational energy dissipation of Etrans and Erot and rotational energy replenishment of S contribute the decrease of the free energy F during τw.

Collision between the same mass particles can transfer energy most efficiently. The water molecule is not exactly a perfect sphere and the two hydrogens are sticking on the water sphere surface. The rotation of the water sphere is that of the two hydrogen atoms around the oxygen nucleus as the centre of gravity. The dissipation and enhancement of the translational motion are mainly controlled by the impulse exchange between the two centres of gravity (Oxygens) of the centre and surrounding water spheres. Similarly, those of the rotational motion are mainly controlled by the impulse exchange between the two rotating hydrogens of the centre and surrounding water spheres. Although the six spheres can contact at the centre sphere surface at φsur = 60° increments, the water sphere existing in the suction groove region cannot contact the centre sphere surface because φsur,pls < 60°. Although the distance between the centre and surrounding water spheres in the suction groove rotational impulse region is not sufficiently short to contact at their surfaces as shown in Fig. 6, the distance is sufficiently short for the rotating hydrogens to exchange impulses between the centre and surrounding spheres. The two water spheres existing in one rubbing laminar region can contact the centre sphere surface because φsur, pls > 120°. Because the oxygens of the surrounding and centre waters can contact on the surfaces in the rubbing laminar regions, the surrounding water sphere can give impulses as viscosity of the RD to the centre of gravity of the centre water sphere. If one rubbing laminar region and one suction groove region exist, the centre of gravity of the water sphere may shift in perpendicular to the directional axis due to impulses. Thus, the two rubbing laminar fluid drag regions and two suction groove regions exist face to face in symmetrical positions. Although the stride of one translational random walk Vth・τw is 0.04Å at 20℃, which is less than 3% of the water sphere radius 1.44Å, and there are gaps among the centre and surrounding spheres as shown in Fig. 6, the Avogadro number average enables the area ratio Γ to divide the rubbing laminar fluid drag and suction groove regions under the smeared background assumption where the water spheres are treated as a continuous medium.

Discussion

It is possible to calculate the volume occupied by one water molecule in ice in which molecules are regularly arranged. The analysis of the molar heat capacity shows that the rotational freedom of water molecules is conserved in the liquid in which the molecules are not arranged. The facts that ice nuclei remain in the liquid water and hydrogen-bonded clusters exist above the m.p. are quantitatively estimated by the low-frequency dielectric ratio, [31, 32] entropy change in solid-liquid transition, correlation among oxygen positions clarified by X-ray analysis, and maximum density temperature of 3.98℃ above the m.p. of 0.00℃. Under these situations we analysed the volume of the sphere that is conserved for RBM of the liquid water molecule, of which the electron cloud is not a perfect sphere.

The sphere radii H2Oaw b of H2O and D2Oaw b of D2O in the vapour state are determined to be H2Oaw b = 1.4445 Å and D2Oaw b = 1.4532 Å, respectively, which are calculated using the van der Waals b constant. Although the calculation method cannot determine the temperature dependence of the sphere radius, it can be determined that the radius D2Oaw b of D2O is greater than that H2Oaw b of H2O by 0.55% because the method has four-digit accuracy. The sphere radii H2Oaw b and D2Oaw b calculated using the van der Waals b constant could become the basis of the sphere radii of H2O and D2O, respectively, despite the fact that these molecules are not perfect spheres.

When the molecules in the liquid state can be assumed to be spheres, the radius of the sphere, which is called the volumetric radius avol was calculated using the liquid density changing with temperature. The minimum volumetric radii H2Oavol,min of H2O at 0℃ and D2Oavol.min of D2O at 10 ℃ were 1.9253 Å and 1.9282 Å, respectively. The thermal expansion rates vol of H2Oavol of H2O from 0 to 50℃ and D2Oavol of D2O from 10 to 50℃ were calculated to be vol =7.9×10-5 /℃. The D2Oavol.min is greater than H2Oavol, min by 0.15%. Although the 0.15% difference between D2Oavol.min and H2Oavol,min is less than the 0.55% difference between H2Oaw b and D2Oaw b, it was determined that the D2O sphere radius is larger than the H2O sphere radius by the order of 0.1%. The thermal expansion rate vol =7.9×10-5 /℃ could become the basis of the radius expansions of H2O and D2O with temperature in the measurements using RBM and TBM.

The sphere radii H2Oaw of H2O and D2Oaw of D2O were calculated to be 1.44±0.01 Å at 0℃ and 1.45±0.01 Å at 10℃ by substituting dielectric relaxation time τrel, viscosity η, and temperature T into the DRF. Because H2Oaw and D2Oaw change with temperature, and 0℃ and 10℃ are close to the maximum density temperatures of 3.98 ℃ for H2O and 11.6 ℃ for D2O, respectively, H2Oaw of H2O at 0℃ and D2Oaw of D2O at 10℃ became the basis of the sphere radii of H2O and D2O performing rotational Brownian motion (RBM) in the liquid state. The radius expansion rates rot of H2O from 0 to 50℃ and D2O from 10 to 50℃ were found to be rot =(3.0±0.6)×10-

4 /℃. Because the dielectric relaxation time measurements were conducted for comparing the orientation characteristics of H2O and D2O molecules in liquid and various ice crystal structures and not for calculating the sphere radii, the temperature dependence of the calculated radii of H2O and D2O showed fluctuating curves. The error width ±0.01Å in H2Oaw at 0℃ and D2Oaw at 10℃, and that ±0.6×10-4 /℃ in the radius expansion rate rot are determined by the fluctuating curves. Thus, the dielectric relaxation time measurement did not have a sufficient accuracy to discriminate the sphere radius difference between H2O and D2O. Because the sphere radii H2Oaw at 0℃ and D2Oaw at 10℃ are close to H2Oaw b and D2Oaw b, respectively, the sphere radii performing RBM in the liquid state were found to be similar to those of a single molecule in the vapour state, which is determined by the van der Waals b constant. The dielectric relaxation time τrel measurement in the picosecond time scale was found not to be affected by the hydrogen-bonded cluster having longer time scale. The rotational freedom in the liquid water molecule supported by the molar heat capacity 18.2(R/2) was also supported by the relations of H2Oaw <H2Oavol and D2Oaw <D2Oavol.

Because the van der Waals b constant showed that D2Oaw b is greater than H2Oaw b by 0.55 %, and the liquid density showed that D2Oavol.min is greater than H2Oavol,min by 0.15%, the possibility to discriminate the radius difference between H2O and D2O by the calculation using the DRF was investigated. The rotational acceleration by the electric field can be ignored because the accelerated rotational velocity was as low as 10-9 of the thermal rotational velocity. The calculation of D2Oaw, min at 5℃ using the DRF as shown in Table 4 may contain a certain error because the viscosity of D2O at 5℃ was determined from the interpolation of the η of D2O between 3.81℃ and 10℃ using Eq. (3.1) [25, 26]. The apparent factor to lower the accuracy in calculating the molecular radius using the DRF is the solvent viscosity. If the viscosities of H2O at 3.98℃ and D2O at 11.6℃, which are the maximum density temperatures, are determined with three- to four-digit accuracy, the sphere radii of H2O and D2O in the liquid state will be discriminated using the DRF.

The distance of the translational motion during one time step τp of rotation is given as Vth・τp. Assuming that the translational random walk changes the direction within the distance Vth・τp, the centrifugal force Fw acting on the centre of gravity is given as Fw= kBT/( Vth・τp) [= MVth 2/( Vth・τp)] when the translational motion changes the direction by 90°, while the centrifugal force FH acting on the rotating hydrogen is FH=2kBT/rOH. The ratio FH/Fw is derived as FH/Fw = 2(Vth・τp)/rOH and numerically calculated to be 2.08×10-3 [= 2・367・0.271×10-15/0.9575×10-10] at 20℃, which is the gyro effect that the molecular rotation impedes the course change of the translational random walk. Thus, the accuracy of the DRF may be affected by the gyro effect with 10-3 order.

The Stokes radius H2Oa of H2O is calculated by substituting the diffusional coefficient D, η, and T into the SEE. The Stokes radius expansion rate trans was 2.0×10-3 /℃. Although η at 0 °C is three times as large as that at 50 °C, the radius increments from 0 to 50℃ due to the expansion rates of rot and trans are as low as 1.5% [= (50-0) × 3.0×10-

4] and 10 % [= (50-0) × 2.0×10-3], respectively. However, it was pointed that Walden’s law does not hold in the SEE because the 10% increment of the Stokes radius is too great in comparison with the radius increment 0.4% [= (50-0) × 7.9×10-5] due to thermal expansion rate vol [11, 12, 13]. It can be assumed that Walden’s law holds in the DRF if the 1.5% increment of the sphere radius is allowable, which is four times greater than that due to the thermal expansion rate vol. Although RBM and TBM occur simultaneously, an essential difference in evaluating the water radius between RBM and TBM was found because trans is six times as large as rot. Even if rot is smaller than trans, a problem of the DRF remains that rot is four times as large as the thermal expansion vol.

Stokes’ law is applicable to the EPF because the electrophoretic velocity vep is faster than the thermal velocity and the electric energy inducing the vep is supplied from the outside of the system. However, there is a possibility that a finite part of the sphere surface cannot receive the RD described by Stokes’ law when the molecular sphere receives both impulses to increase and decrease the translational and rotational motion energies from the surrounding solvent. Thus, the surface of the water sphere performing TBM was divided into the rubbing laminar fluid drag (active RD) and suction groove (inactive RD) regions in order to reduce the RD in the denominator of the SEE. It was expected that the Stokes radius of water calculated using the SEE increases up to a reasonable value due to the reduction of the RD caused by the suction groove region where the water sphere receives the rotational energy 41 times during one translational random walk time step and does not receive the RD for decelerating the translational motion. Although the suction groove region is too narrow for the two water spheres to contact on their surfaces, the exchange of the rotational energy between the surrounding and centre water molecules is efficiently performed through contacts between rotating hydrogens protruding from the water sphere surface. The energy supply to the rotational freedom during one translational random walk determined the reduction rate of the RD. The division of the molecular sphere into the active and inactive RD regions was expected to improve the inaccuracy of the SEE without using the slipping condition. Because the SEE also has the inaccuracy that the Stokes radius varies with temperature, detailed investigations on the SEE will be reported later.

Conclusions

The molecular sphere radii of H2O and D2O in the liquid state to achieve rotational Brownian motion were found to be similar to those in the vapour state because those calculated using the dielectric relaxation formula (DRF) matched the radii calculated using van der Waals b constant. The Stokes radius of H2O is calculated using the Stokes-Einstein equation (SEE), which relates the molecular radius with the diffusion coefficient in translational Brownian motion. The thermal expansion rate of the water sphere radius is calculated using the liquid density decrease with temperature from 0 to 50℃. The advantage of the use of the DRF in the calculation of the water sphere radius was confirmed because the radius expansion rate calculated using the DRF is much closer to the thermal expansion rate than that calculated using the SEE.

Acknowledgement

T.O. is grateful to the late Dr. T. Yasuda a Professor Emeritus of Tokyo Institute of Technology for his insightful contributions.

Competing Interests

I have no competing interests.

Funding

There is no funding.
